9. When the sample gas of the AG module is compatible with the biological compatibility

standard, the sample gas can be returned to the patient circuit. Depress the metal clip and

then plug the exhaust tube to the sample gas return port.

10. When the sample gas of the AG module is not compatible with the biological compatibility

standard, the sample gas needs to scavenge the waste gas to the AGSS.

 Active AGSS

Connecting to the AG module

Sample gas return port

PN:115-052162-00
