5-26

3. Set the calibration device as described below.

To set the VT-Plus, perform the following operations:

a. Pressure settings: Press the PRESSURE button on the front calibration control panel. Select

Range and then set it to Low Press.

Connected to the

syringe

Connected to the pressure test

equipment
