Mindray A8 Service Manual

11-7
No. Name P/N Test Item After
Replacement
Remarks
6
Display board
FRU of status
screen
115-077964-00(A9 US)
5.1 Power-on self-test;
5.7.1 Vaporizer Monitoring
Function Test
Upgrade the
software
package after
the
maintenance.
7
Small-display
service part
115-066860-00
5.1 Power-on self-test;
5.7.1 Vaporizer Monitoring
Function Test
/
8
Optical Encoder
24detent 5 VDC
Cable
010-000257-00
5.1 Power-on self-test. Verify
the functions of the rotary
encoder;
5.7.1 Vaporizer
Monitoring Function Test
The knob is
included.
9
Segment LCD,
I2C interface,
10-pin FPC
021-000481-00
5.7.1 Vaporizer Monitoring
Function Test; Turn on the
auxiliary O2/air module or
high-flow O2 therapy module
to check whether the segment
LCD is on.
/
10
BFCS keyboard
PCBA
051-002581-00
5.7.1 Vaporizer Monitoring
Function Test; Turn on the
auxiliary O2/air module or
high-flow O2 therapy module
to check whether the segment
LCD is on.
/
