2-24
C7
AC input interconnection line
C8
AC-to-DC line
C9
Connection line between the battery
adapter board and the DC-DC board
C10
Connection line between the CPU
board and motherboard
C11 HDMI network cable C12
Connection line between the
motherboard and the I/O interface
board
C13
Connection line between the
motherboard and the small-display
CPU board
C14 System switch line
C15 Backlight board connection line C16
Connection line between the auxiliary
O2/air assembly and the small-display
CPU board
C17 IVO display connection line C18
Connection line of the auxiliary O2/air
keyboard
C19
Connection line between the auxiliary
O2/air assembly and the small-display
CPU board
C20
Connection line between the
motherboard and the gas supply
pressure monitoring board
C21
Connection line of the O2 pressure
switch at the gas inlet
C22 High-flow sensor connection line
C23
Connection line of the auxiliary
O2/air valve
C24
Connection line between the
motherboard and the auxiliary O2/air
assembly
High-flow valve connection line
C25
Connection line between the
motherboard and the sensor adapter
board
C26
Connection line of the zeroing
three-way valve
C27
Pneumatic assembly connection line
C28
APL indicator connection line
C29
Circuit switch line
C30
Sodalime canister switch line
C31 O2 cell connection line C32
Connection line of the expiratory
valve assembly
C33
VR switch connection line
C34
Electronic vaporizer power line
C35
Electronic vaporizer communication
line
C36
Connection line between the
motherboard and the AGSS
C37
Connection line between the
motherboard and the internal AG
module
C38
Three-way valve line of the internal
AG module
C39
Connection line between the
motherboard and the module rack
C41 Electronic flowmeter sensor line
C42
Electronic flowmeter valve line
C43
Auxiliary output connection line
C44
Auxiliary outlet line
/
/
M1
Electronic vaporizer
M2
Vaporizer base valve assembly
M3
Internal AG module
M4
Module rack
