Accutorr 7 Operator’s Manual 13 - 3
■ The recorder runs out of paper.
■ When the recorder has an alarm condition.
When a recording is stopped, the following markers will be added:
■ Automatically stopped recording: print two columns of ‘*’ at the end of the
printout.
■ Manually or abnormally stopped recording: print one column of ‘*’ at the end of
the printout.
13.5 Reports
13.5.1 Real-time Recording
Real-time recording strip includes recording time, parameter values displayed on the
screen, as well as SpO
2
waveform, patient information and manual inputs as configured
in the [Print Setup] menu.
13.5.2 Graphic Trend Recording
Graphic trend strip includes patient information, recording time, and graphic trends of
all the parameters on the screen.
In graphic trends strip:
■ The mark "A" is shown on the event time.
■ NIBP measurement taken in Spot Check mode shows as “ ”.
■ The predictive temperature and PR (from NIBP) measurement show as “■”.
13.5.3 Continuous Trends Recording
The continuous trends strip includes patient information, recording time, measured
value, the saving time for each measurement, and NIBP and Temp complete time.
To print the continuous trends,
1. Choose one patient, and then select [Record] in the [Continuous Trends] screen.
2. Set the start and end time for the recording.
3. Select [Record] to start recording.
In the continuous trends strip:
■ The mark ‘?’ before the time indicates that system time is changed.
■ The mark ‘*’ before the parameter value indicates that an alarm is triggered.
