3 - 6 Accutorr 7 Operator’s Manual
3.4.2 Using the Knob
Using the knob on the front panel of the monitor can do the following operations:
■ Rotate the knob clockwise or counterclockwise to move the cursor.
■ Press the knob to select one item, such as accessing a menu or confirming the
selection
3.4.3 Using the Touchscreen
Select screen items by pressing them directly on the monitor’s screen.
You can disable touchscreen operation by pressing and holding the [Main] QuickKey for
3 seconds. Then a padlock symbol on the [Main] QuickKey is displayed.
When the screen is locked, you can enable the touchscreen operation by pressing and
holding the [Main] Quickkey for 3 seconds.
3.5 Using the Timer
The monitor has a Timer function to notify you when a preset time period is expired.
3.5.1 Displaying the Timer
To display the timer, follow this procedure:
1. Select the [Main] Quickkey.
2. Select [Timer >>] to enter [Timer] window.
3.5.2 Controlling the Timer
The timer provides the following controls:
■ Select [Setup] to access the [Timer Setup] window, in which you can set the
[Direction] to [Up] or [Down]. If you select [Down], you should set:
◆ [Run Time(h:min:s)]: The available time range is 0 to 100 hours, and the
default time is 5 minutes.
◆ [Reminder Vol]: During the last 10 seconds of the countdown, the system
issues a reminder tone. The available volume range is 0 to 10. 0 means off,
and 10 the maximum volume.
■ Select [Start] or [Pause] to start or pause the timer.
■ Select [Clear] to clear current timing result.
