A - 12 Accutorr 7 Operator’s Manual
Accuracy* Full accuracy mode:
0≤CO
2
<1%:
1%≤CO
2
<5%:
5%≤CO
2
<7%:
7%≤CO
2
<12%:
12%≤CO
2
≤13%:
13%<CO
2
≤20%:
±0.1%
±0.2%
±0.3%
±0.4%
±0.5%
±0.43%+8% rel
ISO accuracy mode: Add ±0.3% ABS to the full accuracy
mode
Start-up time 20 s (typical), 90 s (maximum)
Accuracy drift Meets the requirement for measurement accuracy within 6
hours.
Resolution 1mmHg
Sample flowrate Connecting the Oridion sampling line: 50 ml/min
Sample flowrate tolerance ±15% or ±15 ml/min, whichever is greater.
Rise time Measured with a Oridion sampling line: ≤250 ms @ 50 ml/
min (standard sampling line) or ≤280 ms @ 50 ml/min
(extended sampling line)
Response time Measured with a Oridion sampling line: ≤5 s @ 50 ml/min
(standard sampling line) or ≤6.5 s @ 50 ml/min (extended
sampling line)
awRR measurement range 0 to 150 rpm
awRR accuracy <60 rpm: ±1 rpm
60 to 150 rpm: ±2 rpm
awRR resolution 1 rpm
Alarm limit Range Step
EtCO
2
High (low limit + 2) to 99 mmHg 1 mmHg
EtCO
2
Low 1 to (high limit - 2) mmHg
FiCO
2
High 1 to 99 mmHg
awRR High Adult, pediatric: (low limit +
2) to 100 rpm
Neonate: (low limit + 2) to
150 rpm
1 rpm
awRR Low 0 to (high limit - 2) rpm
