rate is larger than the set value, the system will save the image files in a frame
rate of the set value, and transfer in a frame rate of B mode.
Images of PW/M/TVM/TVD mode (B image is frozen), the system will
save/transfer the images files in frame rate of 6.
PRINT SERVICE PRESET
1. On the DICOM Service screen, click the [Print] page tab to enter the Print page.
2. 2. Select a device from the drop down list and enter the corresponding AE Title,
port, etc.
3. Click [Add] to add the service to the Service List.
DICOM print preset items are described as follows:
After you set the server (s) in DICOM Preset screen, the
name (s) will appear in the drop-down list, select the name
of the print server.
Default is xxx-Print, user-changeable.
Application Entity title, here, it should be consistent with that
of the print server.
DICOM communication port, 104 is default. Here, the port
should be consistent with that of the print server port.
To Next Page
