Bit Description
50 = scale interval "50"
LASTERROR Last error byte; see also CmdError bit, number of "last error":
31 = no standstill was reached (e.g.when taring).
33 = negative weight value when taring and legal-for-trade mode
on.
47 = no zero setting; weight not within zero setting range.
107 = no standstill with Getxtare.
12.2.6.6 Register 5: Device type and software release (Read)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 TYPE MSB
Byte 1 TYPE LSB
Byte 2 MAIN VERSION
Byte 3 SUBVERSION
e.g.: 5220 Rel 1.23 = 52200123
hex
12.2.6.7 Register 6: Board number (Read)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 board number MSB
Byte 1 board number MSB
Byte 2 board number MSB
Byte 3 board number LSB
e.g.: 148388723 = 08D83B73
hex
12.2.6.8 Register 7: reserved
12.2.6.9 Registers 8…15: Weight data (Read)
The gross, net, and tare weight are stored as DINT x point. The real data value is derived
from DINT and EXPO as follows:
Value
Real
= reading
DINT
× 10
(-EXPO)
Register 8 Current gross value
Register 9 Current net value, if tared; otherwise gross
Register 10 Current tare value, if tared, otherwise 0
Register 11 Value in the front readout
Register 12 Reserved
Register 13 Reserved
Register 14 Max (FSD)
Transmitter Series PR 5220 12 Fieldbus interface
