Register 15 Reserved (free)
12.2.6.10 Registers 24…29: Limits(Read/Write)
Register 24 Limit 1 on
Register 25 Limit 1 o
Register 26 Limit 2 on
Register 27 Limit 2 o
Register 28 Limit 3 on
Register 29 Limit 3 o
12.2.6.11 Registers 30, 31: Fixed values (Read/Write)
Register 30
Fixed value for analog output; value (num) 020000 corresponds to
20 mA
Register 31 Fixed value for preset tare, see also SetFixTare, GetFixTare in Chap-
ter 12.2.6.3.
12.2.6.12 Registers 80…89: State-controlled action bits (Write)
Note:
For setting bits, see Chapter 12.2.4.3.
Only setting and resetting of single bits is possible.
When changing a bit from 0 to 1, the corresponding action starts. After handling the
command, the bit must be reset. Application: The master writes cyclically.
The bit is set as Write_Value_Select with the specied number (see Chapter 12.2.4.3).
The bit is reset at the specied number +128.
Register 80 SetZero Set the gross weight to zero.
Register 81 SetTare Execute taring.
Register 82 ResetTare Reset tare.
Register 83 SetTest Start the ADC test.
Register 84 ResetTest Finish the ADC test.
Register 85 ResetPwf Reset the PowerFail bit (Register 1; the bit was
set after power on).
Register 86 SetFixTare Taring with weight in numerical address D 31
"Fixtare."
Register 87 GetFixTare The current gross weight is copied into numeri-
cal address D31.
Register 89 ResetError The CmdError error bit is reset.
