Bytes 063
Name Type of data Function
Byte 31 Reserved
Byte 3235
Gross lling result DINT/REAL
Byte 3639
Tare lling result DINT/REAL
Byte 4043
Net lling result DINT/REAL
Byte 4447
Set point lling result DINT/REAL
The lling results are stored after lling and
only overwritten when there is a new result.
Byte 4851
Date of lling result DINT Example:
20161116h corresponds to November 16,
2016
Byte 5255
Time of lling result DINT Example:
14153199h corresponds to 14:15:31 and
99 ms
Byte 5659
Sequence number of lling re-
sult
DINT Sequential number
Byte 60 Filling result status BYTE 1 = successful, 2 = tolerance alarm, 3 = can-
celed
Byte 6162
Reserved
Byte 63 "Last_Error" error The last error number is retained until it is
reset (for possible errors see Chap-
ter 16.6.2).
12.3.5.2.2 Material data
The rst 15 bytes and byte 63 (Last_Error) correspond to the layout of the system data.
Bytes 063
Name Type of data Function
Byte 0 TableSelect USINT Content of read data:
0 = system data, 1 = material data
Byte 1
Bit 0: MSB
Bit 0: ADC error
Bit 1: above max. + still permis-
sible range (OVL)
Bit 2: above max. (FSD)
Bit 3: below zero
Bit 4: zero ±¼ d
Bit 5: within zero set range (ZSR)
Bit 6: weight is stable
Bit 7: weight above max. (FSD)
and below overload
BOOL
Transmitter Series PR 5220 12 Fieldbus interface
Minebea Intec EN-208
