Bytes 063
Name Type of data Function
Byte 2 Bit 0: trigger material data rea-
ding
Bit 1: change calibration
Bit 2: tare
Bit 3: reserved
Bit 4: reserved
Bit 5: power failure (power fail)
Bit 6: within menu [Set-
up]/[Conguration]
Bit 7: lling mode
BOOL Bit 0:
Reading of material data was triggered by
the eldbus.
Bit 1:
Calibrate weighing point.
Bit 2:
Set tare of the instrument.
Bit 5:
After a power failure the bit is set and can
be reset by bit 0 in byte 2.
Bit 6:
Filling is not possible within the menu
items.
Bit 7:
status-controlled: 0 = ll, 1 = empty
Byte 3 Bit 0: error in the application
Bit 1: lling is active
Bit 2: system ready
Bit 3: lling stopped
Bit 4: coarse ow
Bit 5: ne ow
Bit 6: calming time
Bit 7: tolerance alarm
BOOL Bit 0:
Error bit was set.
Bit 1:
The lling phase is active.
Bit 2:
The system is ready for lling.
Bit 3:
Filling was stopped.
Bit 4:
System is lling: coarse ow bit is set.
Bit 5:
System is lling: ne ow bit is set.
Bit 6:
The bit is set according to the set calming
time.
Bit 7:
alarm if tolerance is above/below set point
Byte 47
Gross DINT/REAL Weight
Byte 811
Net DINT/REAL Weight
Byte 1215
Tare DINT/REAL Weight
Byte 16 Material ID BYTE Current material ID
Byte 17 Reserved
Byte 1835
Material name STRING_18 Current material name
Byte 3639
Set point DINT/REAL Current set point
Byte 4043
Preset DINT/REAL Current set point
Byte 4447
Material overshoot (OVS) DINT/REAL Current set point
Byte 4851
Calming time DINT Current set point
Byte 5255
Tolerance above set point DINT/REAL Current set point
12 Fieldbus interface Transmitter Series PR 5220
EN-209 Minebea Intec
