SPM address Type of data R/W Function
B146
X1168
X1169
X1170
X1171
X1172
X1173
X1174
X1175
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
W
W
W
W
W
W
W
W
W
EasyFill only: Filling commands 1
Start lling with the current data record:
Start/restart
Stop/cancel
Load a dened material and start at the same time:
Start ID 1
Start ID 2
Start ID 3
Start ID 4
Start ID 5
Start ID 6
B147
X1176
X1177
X1178
X1179
X1180
X1181
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
W
W
W
W
W
W
W
EasyFill only: Filling commands 2
Start ID 7
Start ID 8
Start ID 9
Start ID 10
Print report
Reset error status D67 = 0
B148
X1182
X1183
BYTE
BOOL
BOOL
W
W
W
EasyFill only: Filling commands 3
Load selected material
Save selected material
B149 BYTE R/W EasyFill only: Filling modes (1 = B1; 2 = B4)
W76 DINT R/W EasyFill only: Material ID
B156173
BYTE R/W
EasyFill only: Material name for ID110
D44 DINT R/W EasyFill only: Set point
D45 DINT R/W EasyFill only: Preset
D46 DINT R/W EasyFill only: Material overshoot (OVS)
D47 DINT R/W EasyFill only: Calming time [ms]
D48 DINT R/W EasyFill only: Tolerance below set point
D49 DINT R/W EasyFill only: Tolerance above set point
W104 (B208) WORD R EasyFill only: Report: Material ID
B212229
BYTE R EasyFill only: Report: Material name
D58 DINT R EasyFill only: Report: lled weight
D59 DINT R EasyFill only: Report: Set point
D60 DINT R EasyFill only: Report: Preset
D61 DINT R EasyFill only: Report: Material overshoot (OVS)
D62 DINT R EasyFill only: Report: Calming time [ms]
D63 DINT R EasyFill only: Report: Tolerance below set point
D64 DINT R EasyFill only: Report: Tolerance above set point
