7.12.3.2 Modifying a calibration
Note:
[Modify] may be used only for minor changes (e.g.changing the dead load, adapting
mV/V values for dead load and/or Max). Otherwise, always use [New]!
Example:
Resetting the Dead Load
7. Calibrating with load [Max at], see Chapter 7.12.7.
8. Calibrating with mV/V [Max at], see Chapter 7.12.8.
9. Calibrating with load cell data (smart calibration) [Max at], see Chapter 7.12.8.1.
10. Carrying out linearization, see Chapter 7.12.11.
1. Select -[Weighing point]- [Calib] and conrm.
2. Press the [Modify] softkey.
3. Choose the [Deadload at] menu item.
4. Either press the [by mV/V] softkey to enter the value again or clear the scale/hopper
and press the [by load] softkey to reset the dead load.
5. Press to exit the calibration.
A prompt window opens.
7 Commissioning Transmitter Series PR 5220
EN-77 Minebea Intec
