MEMORIES AND FILES HANDLED BY CPU MODULE
5.2 High Performance Model QCPU, Process CPU and Redundant CPU
5.2.1 Memory configuration and storable data
5
- 17
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication with
Intelligent Function
Module
8
Parameters
(c) Standard RAM ( Section 5.2.4)
The standard RAM is provided to use the file registers and local devices without
installation of a memory card.
(d) Memory card ( Section 5.2.5)
The memory card is used to increase memory in addition to the built-in memory of
the High Performance model QCPU, Process CPU or Redundant CPU.
An SRAM card, Flash card and ATA card are available as memory cards.
(e) CPU shared memory ( QCPU User's Manual (Multiple CPU System))
The CPU shared memory is used to write/read data between CPU modules of a
multiple CPU system.
