6.21 LED Display
6.21.2 Priority setting
6
FUNCTIONS
POINT
1. When leaving the LED turned off at the error described above, set the factor
No. setting area (each 4 bits), which stores the factor No. corresponding to
SD207 to 209 to "0".
[Example]
To leave the ERR. LED off when a fuse shutoff error is detected, set the factor
No. setting area to "0" where the error No. is "2".
Because the factor No. "2" is not set, the ERR. LED remains off even if
the fuse shutoff is detected. In this case, even if another error with the
factor No. "2" (I/O module verify error or intelligent function module verify
error) is detected, the ERR. LED remains off.
2. If 0 is set to the factor No. setting area (setting that does not turn on the LED),
SM0 (diagnostics error flag) is turned ON, SM1 (self diagnostics error flag) is
turned ON, and the error code is stored into SD0 (diagnostics error register).
Diagram 6.79 Factor No. stored in SD 207 to 209.
SD209 SD208 SD207
00A987654301
