OVERVIEW
1.1 Features
1.1.3 Features of Process CPU
1
- 14
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication with
Intelligent Function
Module
8
Parameters
(4) Module can be replaced online (Online module change)
When a module becomes faulty, it can be replaced without the system being stopped.
Modules available for this are the Q series I/O modules, and the A/D converter
modules, D/A converter modules, temperature input modules, temperature control
modules and pulse input modules of function version C.
Refer to the following manuals for details of the online module change.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
Manuals of the modules compatible with the online module change
(5) Configuration of MELSECNET/H multiplexed remote I/O system
A MELSECNET/H multiplexed remote I/O system can be configured,mounting a
remote master station in the MELSECNET/H network system.
(6) Supporting software package dedicated to process control
Using the process control software package (PX Developer), PID control programs
can be created easily with function blocks.
The combination of the Process CPU and the process control software package (PX
Developer) offers an excellent engineering environment.
POINT
1. When using the Process CPU, use GX Developer Version 7.10L or later.
2. Use PX Developer together with GX Developer Version 7.12L or later.
Refer to the PX Developer manual for details.
