TableApp.18 Special register
Number Name Meaning Explanation
Set by
(When set)
Corres-
ponding
ACPU
D9
Corresponding
CPU
SD90
Step transition
watchdog timer
setting value
(Enabled only
when SFC
program exists)
F number for timer
set value and time
over error
Corresponds to
SM90
• Set the annunciator number (F number) that will
be turned ON when the step transition watchdog
timer setting or watchdog timer time limit error
occurs.
• Turning ON any of SM90 to SM99 during an
active step starts the timer, and if the transition
condition next to the corresponding step is not
met within the timer time limit, the set
annunciator (F) turns ON.
U
D9108
QnA
Qn(H)
QnPH
QnPRH
SD91
Corresponds to
SM91
D9109
SD92
Corresponds to
SM92
D9110
SD93
Corresponds to
SM93
D9111
SD94
Corresponds to
SM94
D9112
SD95
Corresponds to
SM95
D9113
SD96
Corresponds to
SM96
D9114
SD97
Corresponds to
SM97
New
SD98
Corresponds to
SM98
New
SD99
Corresponds to
SM99
New
SD100
Transmission
speed storage
area
Stores the
transmission
speed specified in
the serial
communication
setting.
96 : 9.6kbps, 192 : 19.2kbps, 384 : 38.4kbps,
576 : 57.6kbps, 1152 : 115.2kbps
S (Power-on or
reset)
New
Q00/Q01SD101
Communication
setting storage
area
Stores the
communication
setting specified in
the serial
communication
setting.
* : Since the data is used by the system, it is undefined.
S (Power-on or
reset)
New
SD102
Transmission
wait time
storage area
Stores the
transmission wait
time specifed in
the serial
communication
setting.
0 : No waiting time
1 to F
H
: Waiting time (unit: 10ms)
Defaults to 0.
S (Power-on or
reset)
New
SD105
CH1
transmission
speed setting
(RS232)
Stores the preset
transmission
speed when GX
Developer is
used.
3 : 300bps, 6 : 600bps, 24 : 2400bps,
48 : 4800bps, 96 : 9600bps, 192 : 19.2kbps,
384 : 38.4kbps, 576 : 57.6kbps, 1152 : 115.2kbps
SNew
Qn(H)
QnPH
QnPRH
Rem
SD110
Data sending
result storage
area
Stores the data
sending result
when the serial
communication
function is used.
The error code at data transmission is stored. S (Error)
New Q00/Q01
SD111
Data receiving
result storage
area
Stores the data
receiving result
when the serial
communication
function is used.
Stores the error code at the time of data receiving. S (Error)
b15 b7 b0b8
F number setting
(0 to 255)
Timer time limit
setting
(1 to 255s:
(1s units))
to to
b0
to
b3b4b5b6
b15
to
Sumcheck yes/no
0: No
1: Yes
0: Disabled
1: Enabled
Online program correction setting
