Diagnostics
The Diagnostics screen holds various internal device parameters.
The parameters can only be read and not changed.
Main PCB Temperature Shows the temperature measured on the PCB in the device.
This will always be slightly higher than the surrounding
temperature.
Ambient pressure Shows the currently measured ambient pressure.
Inlet Pressure Shows the current CO
2
concentration in the surrounding
atmosphere.
Package Pressure (Sense) U1 (low range)
U2 (high range)
Currently measured
“SENSE” pressure.
Block Pressure (Feed) U3 (low range)
U4 (high range)
Currently measured “FEED”
pressure.
Sensor Block Sensor block temperature Shows the temperature
measured on the sensor
block.
PWM Sensor block heater power
percentage.
