Mocon AMETEK Dansensor Lippke 5000 - Measurement Accessory Kits; Burst Test Settings

40 User Guide EN Dansensor® Lippke® 5000
P/N 380419-C
05/2022
Measurement accessory kits
The following measurement accessory kits can be used for a Burst test:
 Stand, basic (with any test head and needle or tube adaptor, with or without filter)
 Fixture f. ASTM restraining (with any test head and needle or tube adaptor, with or
without filter)
 PPC 300 II (with or without restraining plate)
 Tube adapter
 IV-Bag adapter
 Valve Test Unit (VTU)
 Hand-held needle, combined
 Hand-held needle, mono
 Hand-held needle, separate Feed and Sense
Burst test settings
For remote controlled devices using the PC software, the test parameters are set in the PC
program.
For a stand-alone device the parameters are set on the device itself - see "Test Definitions" on
page 88 for details.
A Burst test is defined using the following parameters:
Parameters marked with an asterisk (*) are the only parameters that can be changed, when test
definition has already been used for testing
and if the parameter Settings -> Device -> Lock
Test has been enabled.
Name A unique test definition name (up to 30 characters).
Product ID Unique test definition identification code (up to 20
characters).
Standard Test * If set to No, the test definition is not available for the
Standard Test Operator.

Test definition will still be available for an Operator and
Supervisor.
State Only used if Use State Mark is enabled in Settings ->
Device.
Can be used by a Supervisor to categorize the various
test definitions in the test definition list:
New Automatically assigned to new test
definitions.

Can for example be used for test definitions
where settings are still being considered/
tested.
Current Typically used for test definitions that have
been approved for use.

This category of test definitions are the only
test definitions available to the Standard
Test Operator (provided that the Standard
Test option is set to Ye s).
