84 User Guide EN Dansensor® Lippke® 5000
P/N 380419-C
05/2022
Pressure regulator with filters
The filters in the optional pressure regulator unit should be replaced at regular intervals or if
they are soiled.
1. Unscrew the filter bowl .
2. Replace filter:
- The new oil filter element should be clicked into the bowl before assembling it
with the filter housing
.
- The new dust filter element must be screwed onto the threaded rod and
tightened before assembling the bowl
with the filter housing .
CAUTION! All parts should only be hand tightened - do not use any tools.
CAUTION! When assembling the bowls with the filter housings and , make
sure that the O-rings are fitted properly on the bowls.
Draining the filters
If necessary, use the drain valves at the bottom of the bowls to empty them of dirt and
oil residues.
CAUTION! This should be done when the unit is under pressure.
