Dansensor® Lippke® 5000 EN User Guide 29
P/N 380419-C
05/2022
IV-Bag adapter
This is an adapter for testing of IV-bags. The conical shape of the adapter’s mouthpiece allows
for easy connection to most types of IV-bags.
Connect air supply (Feed) and pressure measurement (Sense) hoses to the adapter.
Filter
When testing and afterwards depressurizing packages filled with powder or liquid
substances, there is a risk that particles or fluids can move backwards into the system
potentially causing damage to the instrument.
In these cases it is highly recommended to install the filter in the “FEED” line between the
package and the device.
NOTE! Place the filter as close to the test head or needle as possible to minimize
soiling of the hose.
