Correct use of hose connectors
Follow procedures below to ensure correct and tight hose connections:
Connectors with union nut
1. Unscrew the union nut from the hose connector and slide it onto the hose .
2. Press the hose onto the hose connector as far as it goes.
3. Finally slide the union nut onto the hose connector and tighten properly.
Push-in connectors
1. Push the hose into the fitting as far as it goes. Check the connection by pulling the
hose slightly outwards.
2. To disconnect the hose, push down on the sleeve to release the hose, then pull the
hose out of the connector.
