Moog IMI220-145D001 User Manual

PARISON CONTROLLER
moog
Moog Italiana srl - Bergamo MAN145-UM-D01A-EN 19
2.5.4 Access.
PARISON CONTROLLER manages 3 access levels to protect data entry:
1. minimum access for machine user. Lock: no password inserted.
2. responsible access for responsible. Acc. Resp. For changing this password enter in Technical Level and
enter in setup machine.
3. service access for installer/serviceman. Acc. Tech. This password is fixed by Moog.
Access to levels 2 and 3 is password-protected. Level 2 persists at power down and power up, while level 3 does
not.
2.5.5 Keyboard test page.
From the input/output page and in manual mode (digital input 13 has to be OFF)
Keeping pressed the button F7 (next to the button MENU 2) for 5 seconds it is possible to access the test page
Figure 14
In this page it is possible to:
Reset the password:
Figure 15
Print the pages:
Figure 16
chose the page number and press the softkey
Perform the touch calibration:
-
Figure 17
it is also possible to perform the touch calibration keeping pressed the SET
key (entry knob) for 10 seconds
