Moog IMI220-145D001 User Manual

PARISON CONTROLLER
moog
Moog Italiana srl - Bergamo MAN145-UM-D01A-EN 31
3.4 Analog Input (Card IMI220-6200A001).
Pin n°
Name
Description
1
A1
Positive analog input 1
2
B1
Negative analog input 1
3
PE
Ground pin for connecting ground and shield
4
VR1
+10V reference voltage for sensors
5
0VR1
0V reference voltage return line
6
A2
Positive analog input 2
7
B2
Negative analog input 2
8
PE
Ground pin for connecting ground and shield
9
VR2
+10V reference voltage for sensors
10
0VR2
0V reference voltage return line
11
A3
Positive analog input 3
12
B3
Negative analog input 3
13
PE
Ground pin for connecting ground and shield
14
VR3
+10V reference voltage for sensors
15
0VR3
0V reference voltage return line
16
A4
Positive analog input 4
17
B4
Negative analog input 4
18
PE
Ground pin for connecting ground and shield
19
VR4
+10V reference voltage for sensors
20
0VR4
0V reference voltage return line
3.5 Analog Output (Card IMI220-6260A001).
Pin n°
Name
Description
1
24V
Positive analog input 1
2
GND
Negative analog input 1
3
PE
Ground pin for connecting ground and shield
4
V1
Analog output (voltage) 1
5
0V1
Analog output (voltage) return line 1
6
V2
Analog output (voltage) 2
7
0V2
Analog output (voltage) return line 2
8
V3
Analog output (voltage) 3
9
0V3
Analog output (voltage) return line 3
10
V4
Analog output (voltage) 4
11
0V4
Analog output (voltage) return line 4
12
PE
Ground pin for connecting ground and shield
13
I1
Analog output (current) 1
14
0I1
Analog output (current) return line 1
15
I2
Analog output (current) 2
16
0I2
Analog output (current) return line 2
17
I3
Analog output (current) 3
18
0I3
Analog output (current) return line 3
19
I4
Analog output (current) 4
20
0I4
Analog output (current) return line 4
