PARISON CONTROLLER
moog
52 MAN145-UM-D01A-EN Moog Italiana srl - Bergamo
4.3.2 General setup of the machine.
Number of heads: Select(in manual mode) how many heads are
connected (range 1 ÷ 4).
Number of extruders: Select (in manual mode) how many extruders
have to be managed by the controller. (0 to 2).
Number points profile: Select (in manual mode) how many points
the Parison profile wants (range 10 - 400 points). The change of the
points number of the profile could show some anomalies in the
visualization of the profile shape. It is necessary to reset the old
profiles and draw the new one (see the reference table).
Technician password: Write the password for Technician level. This Password is permanently saved. With this
level password is possible to modify every field.
Responsible password: Write the password for Responsible level. This Password is permanently saved. With
this level password is possible to modify every field but all the setup pages are disabled.
Current language: Select the visualization language. The following languages are available:
English, Italian, German, French, Spanish, Portuguese, Danish, Russian, Turkish, Greek, Chinese, Japanese.
Number synchronisms: Number of synchronisms. The controller can manage up to 5 sync points driving a specific
output. With the Continuous extrusion mode the syncs are edited in the Work Head page where Profile 1 is active.
With Accumulator position mode they are edited in the Accumulator page.
Mode sync 1 (or 2/3/4/5): (visible in Accumulator position mode) Select synchronism mode: Filling, Extrusion or
both. This parameter sets the accumulator movement in which the sync is active.
Default interpolation: Select default interpolation used when you insert a new master in the profile.
4.3.3 How to chose the correct points number:
Task Time is 1 ms if 1 head is active in continuous extrusion mode. Task Time is 2 ms in all other cases.
Reference table:
Points = Cycle time (s) / Task time (s)
