Moog IMI220-145D001 User Manual

PARISON CONTROLLER
moog
Moog Italiana srl - Bergamo MAN145-UM-D01A-EN 67
To better understand how to perform a correct calibration see the following flow chart.
The parameter used to reverse the input polarity is only used during the close loop calibration. In
work mode the polarity is derived by the values of "Vup" and "Vdown" and the polarity reversal
parameter is ignored
Select open loop
calibration
Verify UP/DOWN
movement
Moveme
nt OK
Verify bar graphs
movement
Same
direction
It is possible
the calibration
in close loop
Change the input
wiring or put YES
the input inversion
variable
Change the
output wiring
Put YES the
output inversion
variable
Verify bar graphs
movement
Same
direction
Yes
No
No
Yes
Yes
No
