Morris PROAG 16K PLUS - Page 168

9-32 October 2019 16K PLUS
Hydraulic Assembly
Item Part No. Description Qty
1 10178 Fitting Straight - 08 MORB x 08 MJIC ............................................................................... 2
2 10180 Fitting 90 Elbow - 08 MORB x 08 MJIC............................................................................. 15
3 10187 Fitting-O-Ring Run Tee - 08 MJIC x 08 MJIC x 08 MORB ................................................. 1
4 10436 Bed Cylinder - 5 x 36 x 2 1/2 Dia shaft - 12 ORB (AW-0024) ............................................ 2
5 10439 RT AA Cylinder - 4 1/2 x 8 x 2 Dia shaft - 08 ORB (AW-0027) .......................................... 1
6 10440 LT AA Cylinder - 4 x 8 x 1 3/8 Dia shaft - 08 ORB (AW-0028) ........................................... 1
7 10449 Hitch Cylinder - 3 1/2 x 18 x 1 3/4 Dia shaft - 08 ORB (AU-0478) ..................................... 1
8 10854 Inline Fitting Check Valve .................................................................................................. 1
9 10935 Fitting - Straight - 12 MORB x 12 MJIC ............................................................................. 2
10 K44042 Right Loader Cylinder - 3 1/2 x 19 9/16 - 08 ORB (BJ-0071) ........................................... 1
11 N29356 Fitting - Swivel Nut Run Tee - #12 JIC (11348) ............................................................... 4
12 11350 Fitting - Straight - 20 ORB x 16 JIC ................................................................................... 2
13 11351 Fitting - Reducer - 16 JIC x 12 JIC .................................................................................... 2
14 11353 Fitting - Straight - 04 MORB x #4 MJIC ............................................................................. 2
15 K47925 Adaptor - Straight - 04 ORB x 08 JIC ................................................................................ 1
16 11355 Fitting - Straight - 16 MORB x 08 MJIC - Prior to Serieal Number K161605361 ............... 8
N29359 Connector - 08 MJIC x 10 MORB - Serieal Number K161605361 to present .............. 8
17 11356 Fitting - Straight - 16 MORB x 12 MJIC ............................................................................. 8
18 11357 Fitting - 90 Elbow - #4 FJIC x #4 JIC ................................................................................. 2
19 11358 Fitting - 90 Elbow - 08 FJIC x 08 MJIC ............................................................................ 3
20 11359 Fitting - 90 Elbow - 12 FJIC x 12 MJIC............................................................................... 4
21 11360 Load Check (Seal Kit K55398 - does 1 cartridge, 2 kits req'd) ........................................ 1
22 11365 Fitting - 90 Elbow - 12 MORB x 12 MJIC ........................................................................... 4
23 11366 Fitting - 90 Elbow - 12 MORB x 08 MJIC .......................................................................... 4
24 11368 Fitting - Union Tee - 12 MJIC ............................................................................................. 2
25 11369 Pressure Reducing Relief Valve (Seal Kit K55398) .......................................................... 1
26 11405 Fitting Swivel Nut Branch Tee - 12 MJIC x 12 FJIC x 12 MJIC ........................................... 3
27 11409 16K Motor .......................................................................................................................... 1
12285 16K Motor Body Seal Kit
12286 16K Motor Shaft Seal Kit
28 K44046 Left Loader Cylinder - 3 1/2 x 19 9/16 - 08 ORB .............................................................. 1
29 11695 16K HAWE Valve 02 .......................................................................................................... 1
30 11723 Cushion Valve - 2000 PSI.................................................................................................. 1
31 K50834 Flat Face Coupler - 3/8 x 08 FORB ................................................................................... 1
32 K50961 Connector - 10 MORB x 08 FORB .................................................................................... 1
33 K48292 Hose Tag - Case Drain ...................................................................................................... 1
34 K48293 Hose Tag - Load Sense ..................................................................................................... 1
35 N34488 Female Quick Coupler - 1/2 x 10 FORB ............................................................................ 1
36 N34498 Male Coupler - 1/2 x 10 FORB .......................................................................................... 2
37 K48291 Hose Tag - Return.............................................................................................................. 1
38 K48290 Hose Tag - Pressure .......................................................................................................... 1
39 11811 Fitting - 45 Elbow - 12 FJIC x 12 MJIC............................................................................... 3
40 11812 Fitting - Straight - 12 MORB x 12 FJIC ............................................................................... 2
41 11845 Hydraulic Hose - 1/2 x 69 Lg - 08 FJIC x 12 FJIC swivel ends - LDR LB, LR, RB ............. 2
42 11846 Hydraulic Hose - 1/2 x 63 Lg - 08 FJIC x 12 FJIC swivel ends - LDR RR .......................... 2
43 11847 Hyd Hose - 1/2" x 34" Lg - 08 MJIC x 08 FJIC swivel end - Tensioner Return .................. 1
44 11849 Hyd Hose - 1/2" x 96" Lg - 08 FJIC x 12 FJIC swivel ends - RT Bed Rod ......................... 1
45 11850 Hyd Hose - 1/2" x 94" Lg - 90 degree 08 FJIC x 08 FJIC - Hitch R&B PO Rod ................. 3
46 11851 Hyd Hose - 1/2" x 75" Lg - 08 FJIC - P/R To Bed HL Ten Ret ............................................ 2
47 11852 Hyd Hose - 1/2" x 75" Lg - 08 FJIC x 12 FJIC swivel ends - RT Bed Piston ...................... 1
48 11853 Hyd Hose - 1/2" x 60" Lg - 08 FJIC x 12 FJIC swivel ends - Lg LT Bed Rod ..................... 1
49 11854 Hyd Hose - 1/2" x 58" Lg - 90 degree 08 FJIC x 08 FJIC - PO Piston ............................... 1
50 11855 Hyd Hose - 1/2" x 52" Lg - 08 FJIC - Hawe To Bed HL-GH, AA ......................................... 4
