16K PLUS October 2019 9-33
Hydraulic Assembly
Item Part No. Description Qty
51 11856 Hyd Hose - 1/2" x 45" Lg - 08 FJIC x 12 FJIC swivel ends - LT Bed Piston ...................... 1
52 11857 Hyd Hose - 1/2" x 27" Lg - 08 FJIC x 12 FJIC swivel ends - Hawe To P/R Pressure.......... 1
53 11858 Hyd Hose - 1/2" x 22" Lg - 08 FJIC x 12 FJIC swivel ends- Hawe To P/R Return .............. 1
54 11860 Hyd Hose - 1/4" x 21" Lg - 04- Hawe DW To M Port ......................................................... 1
55 11861 Hyd Hose - 3/4" x 105" Lg - 12 FJIC - Motor Hoses .......................................................... 2
56 11862 Hyd Hose - 3/4" x 55" Lg - 12 FJIC - Hawe To LC V1 (Piston) ........................................... 1
57 11863 Hyd Hose - 3/4" x 49" Lg - 12 FJIC - Hawe To Cush, Lc V2 (Rod) .................................... 3
58 11864 Hyd Hose - 3/4" x 38" Lg - 12 FJIC - LC To Bed HL .......................................................... 2
59 11868 Hyd. Hose - 3/4" x 92" Lg - 12 MJIC x 12 FJIC swivel end - Hawe Return ....................... 1
60 11869 Hyd. Hose - 3/4" x 81" Lg - 12 MJIC x 12 FJIC swivel end - Hawe Pressure .................... 1
61 N37038 Hydraulic Hose - 3/4 x 84 Lg - 12 MORB x 12 FJIC swivel end ......................................... 2
62 11871 Hyd Hose - 1/2" x 139" Lg - 08 FJIC swivel ends - AA LT RT Connect ............................. 1
63 11872 Hyd Hose - 1/2" x 139" Lg - 08 MJIC x 08 FJIC swivel end - AA Piston (Right) ................ 1
64 11873 Hyd Hose - 1/2" x 99" Lg - 08 MJIC x 08 FJIC swivel end - AA Rod (Left) ........................ 1
65 11874 Hyd Hose - 1/2" x 80" Lg - 08 MJIC x 08 FJIC swivel end - GH ........................................ 2
66 11875 Oil Line - 1/2 x 74 Lg - 08 FJIC - Bed Hard Line 1/2” TEN................................................. 2
67 11876 Oil Line - 1/2 x 80 Lg - 08 FJIC - Bed Hard Line 1/2” GH, AA ........................................... 4
68 11879 Oil Line - 3/4 x 74 Lg - 12 FJIC - Bed Hard Line 3/4” LD Rod ........................................... 1
69 11880 Oil Line - 3/4 x 76 Lg - 12 FJIC - Bed Hard Line 3/4” LD PIS ............................................ 1
70 K44706 Oil Line - 3/4 x 132 Lg - 12 FJIC ........................................................................................ 2
71 K47922 Hydraulic Hose - 1/2 x 146 Lg - 08 FJIC x 08 MJIC ........................................................... 1
72 K47921 Hydraulic Hose - 3/8 x 175 Lg - 90 degree 06 FJIC x 06 MJIC .......................................... 1
73 K47936 Hydraulic Hose - 3/8 x 78 Lg - 06 FJIC x 10 MORB .......................................................... 2
74 K44704 Oil Line - 3/8 x 129 Lg - 06 FJIC ........................................................................................ 1
75 K47926 Oil Line - 1/2 x 129 Lg - 08 FJIC ........................................................................................ 1
76 12025 Bulkhead 2” Clamp - 12 MJIC ........................................................................................... 4
77 12031 Bulkhead 1 1/2” Clamp - 08 MJIC .................................................................................... 5
78 12033 Bulkhead 2” Clamp - 08 MJIC .......................................................................................... 2
79 12035 Bulk Head 1 1/2” Clamp - 06 MJIC ................................................................................... 2
80 12166 Grab Hook Cylinder ........................................................................................................... 1
81 12167 Tensioner Cylinder............................................................................................................. 1
82 12168 Pushoff Cylinder ................................................................................................................ 1
83 12185 To Avoid Damage Decal .................................................................................................... 1
84 K47935 Straight Adaptor - 04 MORB x 06 MJIC ............................................................................ 1
85 11886 Hyd Hose - 1/2 x 25 Lg - 08 MJIC x 08 FJIC swivel end - Tensioner Pressure .................. 1
86 K47937 Hydraulic Hose - 1/2 x 78 Lg - 10 MORB x 08 FJIC .......................................................... 1
87 K50994 Hyd Hose - 3/4 x 22 Lg - 12 MORB x 12 FJIC ................................................................... 1
88 N16399 Check Valve - 12 FORB .................................................................................................... 1
89 N37039 Connector - 10 MORB x 12 MORB ................................................................................... 2
90 N37849 Connector - 12 MORB x 12 FJIC ....................................................................................... 1
91 K53636 Connector - 12 FORB x 08 MNPT .................................................................................... 2
92 K53637 Connector - 10 MORB x 05 MNPT .................................................................................... 2
93 K47326 Arms In Pressure Sensor .................................................................................................. 1
94 K47330 Connector - 9/16-18 FORB x 7/16-20 MORB .................................................................... 1
Serieal Number K161605361 to present
95 K58420 Load Sense Amplifier Valve ............................................................................................ 1
96 K58419 Connector - 04 Male BSPP x 08 Male JIC ..................................................................... 2
97 K59071 Connector - 04 Male BSPP x 08 Female JIC ................................................................. 1
98 K58440 Connector - 12 FJIC x 08 MJIC ....................................................................................... 1
99 K58418 Hyd Hose - 1/2 x 18 Lg - 08 FJIC ..................................................................................... 1
To Next Page
