6-49
iControl Messages
iControl AC
6
Invalid Configuration Input DPM_R, INV CNFG INPUT DPM_R
Description: Door Position Monitoring Rear. The safety system detected an input/safety setting difference
when cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration TALRQ, INVALID CNFG TALRQ
Description: Top Access Landing Rear Qualifier. The safety system detected an input/safety setting differ-
ence when cross checking inputs against configuration.
Car Reaction: Safety OK remains off.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Inventory Cross Check BALRQ, INV INVTRY XCHK BALRQ
Description: Bottom Access Landing Rear Qualifier. The safety system detected a configuration/inventory
(board complement) difference when cross checking board complement against system configuration.
Car Reaction: Safety OK remains off.
Troubleshooting:
1. Verify Configuration settings on Setup > Safety > Configuration tab match car options/wiring. Any rear
door options require a rear door board be attached to the safety expansion bus. Likewise, a rear door
board attached to the safety expansion bus requires at least one rear door option be selected on the
Safety Configuration (Setup > Safety > Configuration tab).
2. If safety configuration is incorrect, make appropriate changes and re-learn new configuration using Learn
operation on Setup > Safety > Configuration tab.
3. Re-learn inventory of boards using Inventory Learn procedure on Setup > Safety > Inventory tab.
4. Reset fault (press the iBox FAULT RESET button).
Invalid Configuration Inventory Cross Check DCCOR, INV INVTRY XCHK DCCOR
Description: Door Close Contact Rear. Safety system detected a configuration/inventory (board comple-
ment) difference when cross checking board complement against system configuration.
Car Reaction: Safety OK remains off.
Troubleshooting:
1. Verify Configuration settings on Setup > Safety > Configuration tab match car options/wiring. Any rear
door options require a rear door board. Likewise, a rear door board requires at least one rear door option
be selected on Safety Configuration (Setup > Safety > Configuration tab).
2. If safety configuration is incorrect, make appropriate changes and re-learn configuration using Learn
operation on Setup > Safety > Configuration tab.
3. Re-learn board inventory using the Inventory Learn procedure on the Setup > Safety > Inventory tab.
4. Reset the fault (press the iBox FAULT RESET button).
Table 6.3 iControl Messages
