6-57
iControl Messages
iControl AC
6
Motor Limit Protection Timer Elapsed, MOTOR LMT TIMED OUT 2
Description: Generated if system requests movement for more than ten minutes but no movement detected.
Car Reaction: Currently for informational purposes only.
Motor Limit Timed Out, MOTOR LIMIT TIMED OUT
Description: Generated if no other fault has been generated and system has attempted to move car for three
minutes with no movement detected or minimum movement for ten minutes.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped. Cancel all calls.
Troubleshooting:
1. Check that Pattern Scaling is not set to 0.0.
2. Check Contract Speed is correctly set.
3. Check pattern voltage to drive (0 - 10V) with meter.
Nudging Front, NUDGING FRONT
Description: Logged when front door nudging operation is invoked.
Car Reaction: Front doors start closing at reduced speed and torque.
Nudging Operation
Description: The doors are operating in Nudging mode. (Passenger operation).
Nudging Rear, NUDGING REAR
Description: This event is logged when rear door nudging operation is invoked.
Car Reaction: Rear doors start closing at reduced speed and torque.
Other Cars Alternate Fire Sensor Recall, OTHER CARS ALT FIRE
Description: Alternate fire recall due to active or latched smoke detector input(s) from hoistway or machine
room of other cars in system.
Car Reaction: Car proceeds to user-defined alternate fire recall floor. Once at recall floor, door operation is
according to user-defined door operation under fire recall operation.
Troubleshooting:
1. If in error, inspect the sensors, inputs, and connections.
2. Related Inputs: Other Cars Alt Recall sensor inputs as indicated on job prints.
Other Cars Main Fire Sensor Recall, OTHER CARS MAIN FIRE
Description: Main fire recall due to active or latched smoke detector input(s) from hoistway or machine room
of other cars in system.
Car Reaction: Car proceeds to user-defined main fire recall floor. Once at recall floor, door operation is
according to user-defined door operation under fire recall operation.
Troubleshooting:
1. If in error, inspect the sensors, inputs, and connections.
2. Related Inputs: Other Cars Main Recall sensor inputs as indicated on job prints.
PARAM CHNG-RESET CAR, see Global Parameter Update, Reset Controller
Passenger Operation, Passenger. Normal operation status message.
Photo Eye Antinuisance
Description: Logged when car calls are canceled due to a user-defined number of car calls being registered
without interruption of photo eye.
Car Reaction: All car calls are cancelled.
Troubleshooting:
1. Check user defined options related to operation. (iView/Car Operation/Passenger/Anti Nuisance.)
2. Check photo eye and related inputs.
Table 6.3 iControl Messages
