9-1
About this Section
This section contains detailed information about:
• iControl AC Specifications (see page 9-2).
• Software Test Point Signals: Descriptions of the signals that can be routed to hardware
and software test points (see page 9-2).
• iBox Field Connections: Descriptions of field input and output connections on the left side
of the iBox, including signal levels in active and inactive states (see page 9-6).
• Terminal Field Connections (see page 9-12).
• System and LAN Ethernet: Information about TCP/IP addresses (see page 9-12).
• TORQMAX F5 Drive v3.xx Parameters Quick Reference: A listing of TORQMAX F5 drive
parameters and their default and typical settings (see page 9-23).
• PowerBack R6 Parameters Quick Reference: A listing of PowerBack R6 Regenerative drive
parameters and their default and typical settings (see page 9-44).
• Magnetek HPV900 Series 2 Parameters Quick Reference: A listing of HPV900 Series 2
Drive parameters and their default settings (see page 9-45).
• Magnetek Quattro AC Quick Reference: A listing of Quattro AC drive parameters and their
default settings. (See page 9-52.)
• TORQMAX F5 Drive v1.xx Setup: Instructions for using the v1.xx keypad and setting up
the v1.xx TORQMAX F5 drive. (see page 9-67.)
• TORQMAX F5 Drive v1.xx Parameters Quick Reference: listing of TORQMAX F5 drive
parameters and their default and typical settings (see page 9-71.)
Reference
