LOCKS/CONTACTS
GS Gate Switch input. The gate switch makes up when the elevator doors close.
When the switch is made, there will be 110 VDC on this input. When the switch is
open, there will be 0 VDC on this input. The gate switch may be wired in series
with other switches or locks on the elevator doors (as shown in the job prints) so
that if any of the switches do not make, the GS input will remain low and the car
will not run.
DLAT Door Lock Access Top input. When a top hoistway access is provided (see INA,
ATU, and ATD), the hoistway door lock associated with that landing is connected
between the #3 bus and this input. When the switch is made, there will be 110
VDC on this input. When the switch is open, there will be 0 VDC on this input and
the car will not run unless INA is active and then only in response to the ATU or
ATD input.
DLMS Door Lock Main String input. If top and bottom hoistway access (see INA, ATU,
ATD, ABU, and ABD) is not provided, all hoistway door locks are wired in series
between the #3 bus and DLMS. When the switches are made, there will be 110
VDC on this input. When any switch is open, there will be 0 VDC on this input and
the car will not run.
DLAB Door Lock Access Bottom input. When a bottom hoistway access is provided (see
INA, ABU, and ABD), the hoistway door lock associated with that landing is con-
nected between the #3 bus and this input. When the switch is made, there will be
110 VDC on this input. When the switch is open, there will be 0 VDC on this input
and the car will not run unless INA is active and then only in response to the ABU
or ABD input.
DCAT Door Contact Access Top input. When a top hoistway access is provided (see INA,
ATU, ATD, and DLAT), the hoistway door contact associated with that landing is
connected between the #3 bus and this input. When the switch is made, there
will be 110 VDC on this input. When the switch is open, there will be 0 VDC on
this input and the car will not run unless INA is active and then only in response
to the ATU or ATD input.
DCMS Door Contact Main String input. If top and bottom hoistway access (see INA, ATU,
ATD, ABU, and ADB) is not provided, all hoistway door contacts are wired in series
between the #3 bus and DCMS. When the switches are made, there will be 110
VDC on this input. When any switch is open, there will be 0 VDC on this input and
the car will not run.
DCAB Door Contact Access Bottom input. When a bottom hoistway access is provided
(see INA, ABU, ABD, and DLAB), the hoistway door contact associated with that
landing is connected between the #3 bus and this input. When the switch is
made, there will be 110 VDC on this input. When the switch is open, there will be
0 VDC on this input and the car will not run unless INA is active and then only in
response to the ABU or ABD input.
GOV Governor input. The governor is connected between the #3 bus and this input.
When the governor switch is made, there is 110 VDC on this input. It the gover-
nor switch trips/opens, there is 0 VDC on this input and the car will not run.
SP 1 Spare input 1. If used, connect as shown in the job prints.
BRAKE
BD Brake Drive relay indicator. When the BD relay on the iBox IRB board is closed to
pick the brake, this LED will light. Monitored by Safety Processor A.
TB Brake Triac active indicator. When the brake triac on the iBox IRB board is active
(completes circuit for BD relay), this LED will light. Monitored by Safety Processor
B.
BRD Brake Redundancy indicator. This LED lights when the main brake contactor drops
out.
BDRD Brake Drive Redundancy indicator. This LED lights when the BD relay drops out.
Table 9.3 iBox Field Connections
