9-13
System and LAN Ethernet
iControl AC
9
Elevator LAN Network
Normally extends throughout a building and may span to other buildings, networks, or loca-
tions across the internet/intranet.
LAN Network Hub (Blue cables)
“= same as above
* = see Note #1
IP Subnet Gateway DNS
(IEEE reserved) 192.168.191.0 255.255.255.0 192.168.191.254 * 192.168.191.254 *
Group 1 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.1 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.2 “ “ “
iBox – Car 3 192.168.191.3 “ “ “
iBox – Car 4 192.168.191.4 “ “ “
iBox – Car 5 192.168.191.5 “ “ “
iBox – Car 6 192.168.191.6 “ “ “
iBox – Car 7 192.168.191.7 “ “ “
iBox – Car 8 192.168.191.8 “ “ “
iBox – Car 9 192.168.191.9 “ “ “
iBox – Car 10 192.168.191.10 “ “ “
iBox – Car 11 192.168.191.11 “ “ “
iBox – Car 12 192.168.191.12 “ “ “
iBox – Car 13 192.168.191.13 “ “ “
iBox – Car 14 192.168.191.14 “ “ “
iBox – Car 15 192.168.191.15 “ “ “
iBox – Car 16 192.168.191.16 “ “ “
iBox – Car 17 192.168.191.17 “ “ “
iBox – Car 18 192.168.191.18 “ “ “
iBox – Car 19 192.168.191.19 “ “ “
iBox – Car 20 192.168.191.20 “ “ “
iView 192.168.191.101 –
192.168.191.102
““ “
iCue 192.168.191.201 –
192.168.191.202
““ “
Group 2 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.21 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.22 “ “ “
iBox – Car 3 192.168.191.23 “ “ “
iBox – Car 4 192.168.191.24 “ “ “
iBox – Car 5 192.168.191.25 “ “ “
iBox – Car 6 192.168.191.26 “ “ “
iBox – Car 7 192.168.191.27 “ “ “
iBox – Car 8 192.168.191.28 “ “ “
iBox – Car 9 192.168.191.29 “ “ “
iBox – Car 10 192.168.191.30 “ “ “
iBox – Car 11 192.168.191.31 “ “ “
iBox – Car 12 192.168.191.32 “ “ “
