9-20 Manual # 42-02-2223
Reference
Group #3 – Floors ( ) Machine Room Floor ( )
Group 4 – Floors ( ) Machine Room Floor ( )
Group #3 - LAN Network (Blue cables)
iBox – Car 1 192.168.191.41 255.255.255.0 192.168.191.254
*
192.168.191.254 *
iBox – Car 2 192.168.191.42 “ “ “
iBox – Car 3 192.168.191.43 “ “ “
iBox – Car 4 192.168.191.44 “ “ “
iBox – Car 5 192.168.191.45 “ “ “
iBox – Car 6 192.168.191.46 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.60 “ “ “
iView
192.168.191.105 –
192.168.191.106
“““
iCue
192.168.191.205 –
192.168.191.206
“““
Group #4 - LAN Network (Blue cables)
iBox – Car 1 192.168.191.61 255.255.255.0 192.168.191.254
*
192.168.191.254 *
iBox – Car 2 192.168.191.62 “ “ “
iBox – Car 3 192.168.191.63 “ “ “
iBox – Car 4 192.168.191.64 “ “ “
iBox – Car 5 192.168.191.65 “ “ “
iBox – Car 6 192.168.191.66 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.80 “ “ “
iView
192.168.191.107 –
192.168.191.108
“““
iCue
192.168.191.207 –
192.168.191.208
“““
