9-21
System and LAN Ethernet
iControl AC
9
Group #5 – Floors ( ) Machine Room Floor ( )
Group #6 – Floors ( ) Machine Room Floor ( )
Group #5 - LAN Network (Blue cables)
iBox – Car 1 192.168.191.81 255.255.255.0 192.168.191.254
*
192.168.191.254 *
iBox – Car 2 192.168.191.82 “ “ “
iBox – Car 3 192.168.191.83 “ “ “
iBox – Car 4 192.168.191.84 “ “ “
iBox – Car 5 192.168.191.85 “ “ “
iBox – Car 6 192.168.191.86 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.100 “ “ “
iView
192.168.191.109 –
192.168.191.110
“““
iCue
192.168.191.209 –
192.168.191.210
“““
Group #6 - LAN Network (Blue cables)
iBox – Car 1 192.168.191.121 255.255.255.0 192.168.191.254
*
192.168.191.254 *
iBox – Car 2 192.168.191.122 “ “ “
iBox – Car 3 192.168.191.123 “ “ “
iBox – Car 4 192.168.191.124 “ “ “
iBox – Car 5 192.168.191.125 “ “ “
iBox – Car 6 192.168.191.126 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.140 “ “ “
iView
192.168.191.111 –
192.168.191.112
“““
iCue
192.168.191.211 –
192.168.191.212
“““
