2-17
Setting Initial Operating Parameters
iControl AC
2
Table 2.2 Recommended iView Starting Values for Initial Operation
iView Screen Settings
Pattern >Common tab
Position Encoder
Resolution
348 if iLand-x-C Compact Landing system. 256 if iLand-x-H or LS-
EDGE. Otherwise, consult manufacturer documentation.
Job Contract Speed 200 fpm 350 fpm 400 fpm 500 fpm 600 + fpm Unit
Pattern scaling 100% 100% 100% 100% 100% %
Door pre-opening dis. 0.00 0.00 0.00 0.00 0.00 inches
Leveling speed 005 005 005 005 005 fpm
Releveling speed 008 008 008 008 008 fpm
Leveling distance 1.20 0.72 0.60 0.60 0.60 inches
Releveling distance 0.60 0.60 0.60 0.60 0.60 inches
Dead zone distance 0.25 0.25 0.25 0.25 0.25 inches
Relevel dead zone dis. 0.15 0.15 0.15 0.15 0.15 inches
Pattern > Modes tab — Standard Profile
Job Contract Speed 200 fpm 350 fpm 400 fpm 500 fpm 600 + fpm Unit
Initial jerk 6.00 6.00 5.00 5.00 6.0
ft/s
3
Acceleration 2.40 3.20 3.40 3.60 3.80
ft/s
2
High toll jerk 6.00 6.00 5.00 5.00 4.00
ft/s
3
High speed 200 350 400 500 600 ft/min
Low roll jerk 6.00 6.00 5.00 5.00 4.00
ft/s
3
Deceleration 2.20 2.90 3.20 3.30 3.50
ft/s
2
Flare jerk 3.00 3.00 3.00 3.00 3.00
ft/s
3
Approach deceleration 1.50 1.50 1.50 1.50 1.50
ft/s
2
Approach jerk 2.00 2.00 2.00 2.00 2.00
ft/s
3
Pattern > Modes tab — Inspection Profile
Job Contract Speed 200 fpm 350 fpm 400 fpm 500 fpm 600 + fpm Unit
Initial jerk 6.00 6.00 5.00 5.00 6.0
ft/s
3
Acceleration 2.40 3.20 3.40 3.60 3.80
ft/s
2
High roll jerk 6.00 6.00 5.00 5.00 4.00
ft/s
3
High speed 30 30 30 30 30 ft/min
Low roll jerk 6.00 6.00 5.00 5.00 4.00
ft/s
3
Deceleration 2.20 2.90 3.20 3.30 3.50
ft/s
2
Flare jerk 3.00 3.00 3.00 3.00 3.00
ft/s
3
Approach deceleration 1.50 1.50 1.50 1.50 1.50
ft/s
2
Approach jerk 2.00 2.00 2.00 2.00 2.00
ft/s
3
Low speed 1010101010 ft/min
General >General tab
Simplex car Set to Simplex if the car is NOT in a group to enable dispatch and
parking screens (limited group functionality for a single car).
