2-18 Manual # 42-02-2223
Construction Mode
Permanent magnet (PM) AC Gearless Machines must by synchronized with the AC Drive. Please
refer to the appropriate section in your drive manual.
Drive >General tab
Drive Type Factory set. Verify drive type selected is correct.
Speed Reference tachometer
Speed ref resolution Velocity Encoder PPR
Rated motor RPM: From motor plate.
Coupling rotational ratio (Brake drum or Sheave Diameter/ Diameter of encoder wheel). If
shaft mounted, set to 1.000
Normal rate limited stop Per job. Default 1 ft/s.
Emerg rate limited stop Per job. Default 7 ft/s.
Drive > Safety tab
Following error 25% (factory shipped default)
Safety > General tab
Pulses Per Foot Display Only
Contract Speed Display Only
Contract Overspeed 107% of Contract Speed
Inspection Overspeed 150 feet per minute
Leveling Overspeed 150 feet per minute
Limit One Margin 8%
Top Access Landing Job specific, check job prints
Top Access Rear Job specific, check job prints
Bottom Access Landing Job specific, check job prints
Bottom Access Rear Job specific, check job prints
No Main String Job specific, check job prints
No Main String Rear Job specific, check job prints
Frnt Door Close Contact Job specific, check job prints
Rear Door Close Cntact Job specific, check job prints
Rear Doors Job specific, check job prints
Freight Door Option 1 Job specific, check job prints
Rope Gripper Check to see if a rope gripper is used
Car Top Exit Check job prints.
Construction Mode Set to ON.
Door Position Monitor Check if used (see job prints)
In Car Panel Inspection Check if used (see job prints)
Table 2.2 Recommended iView Starting Values for Initial Operation
iView Screen Settings
