143
6802800U74-AN
Chapter 4: Hardware Installation
4.13.3
Recommended Parts
The following table lists the parts recommended for installation. Procure the following parts locally as
they are not part of the MTS shipment. All model numbers are Motorola Solutions part numbers unless
noted otherwise.
Table 30: Recommended Installation Parts
Part Type/Size Supplier Where Used
Cover or blanket Locally Procured Protection of cabinet
from dust while drilling
Anchor Kit 10 mm Rawl Bolts (con-
crete fixing bolts)
Locally Procured MTS cabinet floor an-
chors
Grease anti-oxidant Locally Procured Battery terminal corro-
sion control
AC Power Cable mini-
mum size
AC Power Cable max-
imum size
1.3 mm
2
(#16 AWG) Locally Procured Mains Supply wiring
2.1 mm
2
(#14 AWG) Locally Procured Mains Supply wiring
DC Power Cable 3.3 mm
2
(12 AWG)
(Length: more than 3 m)
DC Power Cable 5.3 mm
2
(10 AWG)
(Length: more than 3 m)
Locally Procured DC and Backup Bat-
tery wiring
Locally Procured DC and Backup Batter
wiring
100-240 VAC Con-
nector
Motorola P/N
3166502A01
Supplied with
MTS
AC Mains Connector
-48 VDC Connector MTS 2: Motorola P/N
3166501A01
MTS4: Motorola P/N
3166501A02
Supplied with
MTS
DC Connector Backup
Battery connector
4.13.4
Recommended Torque
The following table lists the recommended torque for RF connectors, screws, nuts, and bolts.
Table 31: Recommended RF Connectors, Screws, and Nuts Torque
Item Torque Nm Torque lbfin
“N” Coupling Nuts 0.68 – 1.13 6.02 10
“SMA” Coupling Nuts 1.0 9
Screws up to M 3.5 0.6 5.31
Nuts up to M 3.5 1.2 for class 80 steel, 0.9 for class
70 steel, and 0.4 for class 50 steel
11 for class 80 steel, 8 for
class 70 steel, and 3.5 for
class 50 steel
Screws M4 (Torx 20) 4.5 40
