Motorola DIMETRA X Core User Manual

316
6802800U74-AN
Chapter 9: XHUB Controller
LED
LED/Port
Name
Position
Controlled
By
Indication
LED14 Port 5 LED2 HW, Enet
switch
OFF: Ethernet activity not
present YELLOW: Ethernet ac-
tivity present
LED15
AUX1
Port 6 LED1 HW, Enet
switch
OFF: Ethernet link not present
GREEN: Ethernet link present
LED16 Port 6 LED2 HW, Enet
switch
OFF: Ethernet link not present
YELLOW: Ethernet link present
LED17
AUX2
Port 7 LED1 HW, Enet
switch
OFF: Ethernet link not present
GREEN: Ethernet link present
LED18 Port 7 LED2 HW, Enet
switch
OFF: Ethernet link not present
YELLOW: Ethernet link present
LED19
Prime Cab
Port 8 LED1 OFF: Ethernet link not present
GREEN: Ethernet link present
Port 8 LED2 OFF: Ethernet activity not
present YELLOW: Ethernet ac-
tivity present
9.2.1.2
XHUB Controller – Front Panel Switches
The following table lists the Front Panel switches of the XHUB Controller and their functions.
Table 93: XHUB Controller – Front Panel Switches
Switch Name Switch Function
Reset The front-panel switch can be used to initiate a Hard
Reset of the XHUB Controller. Push and hold (>3
seconds) for Hard Reset.
9.2.1.3
XHUB Controller – Front Panel Connectors
The following table lists the front panel connectors of the XHUB controller.
Table 94: XHUB Controller – Front Panel Connectors
Connector Name
Connector Type
To/From
Comment
Power
MOLEX (2 Pin)
PSU
28.5 V DC
BR
RJ45
BR
Ethernet
AUX1
RJ45
BR or Ethernet Site-
link
Used in E-Tetra config-
urations or Ethernet Si-
telink
AUX2
RJ45
BR
Used in E-Tetra config-
urations
Service
RJ45
Service Terminal
Provides service ac-
cess
