Motorola DIMETRA X Core User Manual

198
6802800U74-AN
Chapter 5: Interconnection and Internal Cabling
5.5.12
RF Cabling – Expansion Cabinet with One TX/RX Antenna
Table 62: RF Cabling/Connections for Expansion Cabinet with One TX/RX ant. and Up to Two
Additional RX ant.
In-
dex
Cable
Part
Number
From Unit To Unit Notes
1
3066543B
02
Base Radio 5 / RX-
S 1
RX-S 1 / BR 5
RX path / RX on 1 or 2 ant.
2
3066543B
02
Base Radio 6 / RX-
S 1
RX-S 1 / BR 6
RX path / RX on 1 or 2 ant.
3
3066543B
03
Base Radio 7 / RX-
S 1
RX-S 1 / BR 7
RX path / RX on 1 or 2 ant.
4
3066543B
03
Base Radio 8 / RX-
S 1
RX-S 1 / BR 8
RX path / RX on 1 or 2 ant.
5
3066543B
02
Base Radio 5 / RX-
S 2
RX-S 2 / BR 5
RX path / RX on 1 or 2 ant.
6
3066543B
02
Base Radio 6 / RX-
S 2
RX-S 2 / BR 6
RX path / RX on 1 or 2 ant.
7
3066543B
03
Base Radio 7 / RX-
S 2
RX-S 2 / BR 7
RX path / RX on 1 or 2 ant.
8
3066543B
03
Base Radio 8 / RX-
S 2
RX-S 2 / BR 8
RX path / RX on 1 or 2 ant.
9
3066543B
02
Base Radio 5 / RX-
S 3
RX-S 3 / BR 5
RX path / RX on 2 ant.
10
3066543B
02
Base Radio 6 / RX-
S 3
RX-S 3 / BR 6
RX path / RX on 2 ant.
11
3066543B
03
Base Radio 7 / RX-
S 3
RX-S 3 / BR 7
RX path / RX on 2 ant.
12
3066543B
03
Base Radio 8 / RX-
S 3
RX-S 3 / BR 8
RX path / RX on 2 ant.
13
3066543B
08
Base Radio 5 / Tx
ATCC 3 / TX
A
TX path, Coax cable, low loss
14
3066543B
08
Base Radio 6 / Tx
ATCC 3 / TX
B
TX path, Coax cable, low loss
15
3066543B
09
Base Radio 7 / Tx
ATCC 4 / TX
A
TX path, Coax cable, low loss
16
3066543B
09
Base Radio 8 / Tx
ATCC 4 / TX
B
TX path, Coax cable, low loss
17
See Table
ATCC 3 / TX Out
ATCC (3, 4)
TX path, Interconnect Harness
58: TX
ATCC In-
terconnect
Harness
Part Num-
ATCC 4 / TX Out
