6802800U74-AN
Chapter 5: Interconnection and Internal Cabling
154
5.1.4
AC/DC Power Cabling – Expansion Cabinet
Table 36: AC/DC Power Cabling for Expansion Cabinet
In- Cable Part
From Unit To Unit Notes
3066551B01
3 / DC Out
and 13
4c Y Splitter Pins: 7 and 14
4d 3066574B01 Y Splitter XHUB 1 / Power 3
XHUB 2 / Power 3
5a
4 / DC Out
Base Radio 7 / DC In Pins: 1, 2, 3, 8, 10,
and 11
dex
Number
1a
Junction Panel /
Power Supply Unit
N/A
DC1
3/DC In Battery
1b
Junction Panel /
DC2
Power Supply Unit
4/DC In Battery
N/A
2
3066553B01
Junction Panel / AC
In 1
Power Supply Unit 3 /
AC In
With retaining clip
3
3066553B01
Junction Panel / AC
Power Supply Unit 4 /
With retaining clip
In 2
AC In
4a
Base Radio 5 / DC In
Pins: 1, 2, 3, 8, 10,
and 11
4b 3066545B01
Power Supply Unit
Base Radio 6 / DC In
Pins: 4, 5, 6, 9, 12,
5b 3066545B01
Power Supply Unit
Base Radio 8 / DC In
Pins: 4, 5, 6, 9, 12,
and 13
5c
Y Splitter
Pins: 7 and 14
5d
3066574B01
Y Splitter
XHUB1 / Power 4
XHUB 2 / Power 4
6
3066556B02
Junction Panel / Bat
Temp 1
Power Supply Unit 3 /
Battery Temp Sens.
N/A
7
3066556B02
Junction Panel / Bat
Temp 2
Power Supply Unit 4 /
Battery Temp Sens.
N/A
8
3066557B01
Power Supply Unit
3 / ATCC DC Out
ATCC 3 / DC In
Only for configura-
tion with ATCC
9
3066557B01
Power Supply Unit
4 / ATCC DC Out
ATCC 4 / DC In
Only for configura-
tion with two
ATCCs
10
3066559B01
ATCC 3 / Inside
ATCC Interconnec-
tion
ATCC 4 / Inside
ATCC Interconnection
Only for configura-
tion with two
ATCCs
