6802800U74-AN
Chapter 14: Technical Specifications
14.3.2
Dimensions of the MTS Cabinets
The following table lists the dimensions of the MTS LiTE, MTS 2, MTS 4, and MTS 4 Expansion
Cabinets.
Table 118: Dimensions of the MTS 2, MTS 4, and MTS 4 Expansion Cabinets
Physical Dimensions Description
Depth: MTS LiTE: 480 mm
MTS 2: 472 mm
MTS 4: 570 mm
Height: MTS LiTE: 380 mm
MTS 2: 605 mm
MTS 4: 1430 mm
Width: MTS LiTE: 450 mm
MTS 2: 443 mm
MTS 4: 550 mm
Weight: with full equipment:
MTS LiTE: 35 kg
MTS 2: 48 kg
MTS 4: 141 kg
with full equipment incl. packaging:
MTS LiTE: 51 kg
MTS 2: 64 kg
MTS 4: 170 kg
14.3.3
RF Specifications
Table 119: RF Specifications
RF Specifications Description Value or Range
Frequency Low 400 MHz band (TETRA and
TEDS):
High 400 MHz band (TETRA and
TEDS):
350 MHz 430 MHz
380 MHz 470 MHz
260 MHz (TETRA) 260 MHz – 275 MHz
800 MHz (TETRA and TEDS): 806 MHz – 870 MHz
900 MHz (TETRA and TEDS): 917 MHz – 942 MHz
Duplex spacing: 400 MHz: 10 MHz
260 MHz: 9 MHz
