6802800U74-AN
Chapter 13: MTS Troubleshooting
13.1.2.6
Troubleshooting: BRC Config Files and Code File
The BRC does not boot or operate correctly unless a valid configuration file and code file is stored in
the flash filing system of the Site Controller. Use the method described in Troubleshooting: General
Check of a Site Controller File on page 352 to ensure that the file shown in the following table is valid
for the BR of interest. For Code File, ensure that either brc.code.1 or brc.code.2 is selected as the
current file.
NOTICE: Config files are only present for installed BRCs.
Table 109: BRC Config File Troubleshooting
13.1.2.7
Troubleshooting: General Check of a Site Controller File
To check the validity of a particular file in the Flash File System of the Site Controller, it is necessary to
use the attrib command as explained below.
NOTICE: The attrib command works in Site Controller application as well as in boot1 mode.
This example looks at the configuration file of the Site Controller.
1 Use the attrib command to produce a listing of all files on the Site Controller. Check if the files of
interest do not have any warning after their details. This shows only a small part of the typical
output:
In this example tsc.cf.1 looks like a valid file, whilst brc09.cf.1 has a ‘w’ attribute so it is not valid.
2 Use the attrib tsc.cf* command to produce a listing of the configuration files attributes of the
Site Controller.
Note which file has the ‘c’ (Current) attribute and ensure that it also has the ‘r’ (read) attribute. If the
file has the ‘w’ attribute, it is not valid.
