Motorola DIMETRA X Core User Manual

195
6802800U74-AN
Chapter 5: Interconnection and Internal Cabling
5.5.11
RF Cabling – MTS 4 with One TX Antenna
Table 61: RF Cabling/Connections for MTS 4 with One TX ant. and Up to Three Additional RX ant.
In-
dex
Cable
Part Num-
ber
From Unit / Con-
nection Name
To Unit / Con-
Notes
nection Name
1
3066543B
02
Base Radio 1/ Rx1
Preselector 1/
BR1
RX path/ RX on 2 or 3 ant.
2
3066543B
02
Base Radio 2/ Rx1
Preselector 1/
BR2
RX path/ RX on 2 or 3 ant.
3
3066543B
03
Base Radio 3/ Rx1
Preselector 1/
BR3
RX path/ RX on 2 or 3 ant.
4
3066543B
03
Base Radio 4/ Rx1
Preselector 1/
BR4
RX path/ RX on 2 or 3 ant.
5
3066543B
02
Base Radio 1/ Rx2
Preselector 2/
BR1
RX path/ RX on 2 or 3 ant.
6
3066543B
02
Base Radio 2/ Rx2
Preselector 2/
BR2
RX path/ RX on 2 or 3 ant.
7
3066543B
03
Base Radio 3/ Rx2
Preselector 2/
BR3
RX path/ RX on 2 or 3 ant.
8
3066543B
03
Base Radio 4/ Rx2
Preselector 2/
BR4
RX path/ RX on 2 or 3 ant.
9
3066543B
02
Base Radio 1/ Rx3
Preselector 3/
BR1
RX path/ RX on 3 ant.
10
3066543B
02
Base Radio 2/ Rx3
Preselector 3/
BR2
RX path/ RX on 3 ant.
11
3066543B
03
Base Radio 3/ Rx3
Preselector 3/
BR3
RX path/ RX on 3 ant.
12
3066543B
03
Base Radio 4/ Rx3
Preselector 3/
BR4
RX path/ RX on 3 ant.
13
3066543B
08
Base Radio 1/ Tx
ATCC 1/ TX A
TX path, Coax cable, low
loss
14
3066543B
08
Base Radio 2/ Tx
ATCC 1/ TX B
TX path, Coax cable, low
loss
15
3066543B
09
Base Radio 3/ Tx
ATCC 2/ TX A
TX path, Coax cable, low
loss
16
3066543B
09
Base Radio 4/ Tx
ATCC 2/ TX B
TX path, Coax cable, low
loss
17
3066543B
15
ATCC (1, 2)
Post Filter/ TX
TX path, Post Filter cable
18
See Table
ATCC 1/ TX OUT
ATCC (1, 2)
TX path, Interconnect Har-
58: TX
ATCC In-
terconnect
ATCC 2/ TX OUT
ness
