315
6802800U74-AN
Chapter 9: XHUB Controller
9.2.1.1
XHUB Controller – Front Panel Indicators (LED)
The following table lists the Front Panel LEDs.
Table 92: XHUB Controller – Front Panel Indicators (LED)
LED
LED/Port
Name
Position
Controlled
By
Indication
LED1
Active
Front Panel
SW
GREEN: XHUB is Active and in
Normal mode
OFF: XHUB in Standby or
Standalone/Impaired Normal
mode
LED2
Mode
Front Panel
HW
GREEN: Normal or Impaired
Normal Mode
OFF: Standalone mode
LED3
Link Alarm
Front Panel
HW
RED: Impaired Normal or
Standalone mode
OFF: Normal mode
LED4
Alarm
Front Panel
SW
RED: If Alarms (Problem or
Failure) in Normal mode or Un-
known XHUB state
FLASH: Impaired Normal mode
LED5
Port 1 LED1
HW, Enet
OFF: Ethernet link not present
switch
GREEN: Ethernet link present
LED6
BR5
Port 1 LED2
HW, Enet
OFF: Ethernet activity not
switch
present YELLOW: Ethernet ac-
tivity present
LED7
Port 2 LED1
HW, Enet
OFF: Ethernet link not present
switch
GREEN: Ethernet link present
LED8
BR6
Port 2 LED2
HW, Enet
OFF: Ethernet activity not
switch
present YELLOW: Ethernet ac-
tivity present
LED9
Port 3 LED1
HW, Enet
OFF: Ethernet link not present
switch
GREEN: Ethernet link present
LED10
BR7
Port 3 LED2
HW, Enet
OFF: Ethernet activity not
switch
present YELLOW: Ethernet ac-
tivity present
LED11
Port 4 LED1
HW, Enet
OFF: Ethernet link not present
switch
GREEN: Ethernet link present
LED12
BR8
Port 4 LED2
HW, Enet
OFF: Ethernet activity not
switch
present YELLOW: Ethernet ac-
tivity present
LED13
Service
Port 5 LED1 HW, Enet
switch
OFF: Ethernet link not present
GREEN: Ethernet link present
