Motorola DIMETRA X Core User Manual

212
6802800U74-AN
Chapter 5: Interconnection and Internal Cabling
5.6.2
CAN Bus Cabling – MTS 2
The Site Controller contains the internal termination in one end of the CAN Bus, and the last Duplexer
in the CAN Bus has a terminator in one connector.
NOTICE: CAN Bus cabling depends on filter configuration.
Table 68: CAN Bus Cabling for MTS 2 with TX/RX on 1 ant. RX on 2 ant.
In-
dex
Cable Part
Number
From Unit / Connection
Name
To Unit / Connection
Name
Notes
MTS 2 (TX/RX on 1 ant. RX on 2 ant.)
1 3066575B01 Site Controller/ CAN Power Supply Unit/
CAN1
Red cable
2 3066544B10 Power Supply Unit/
CAN2
Duplexer/ CAN1 Red cable
3 0966513A01 Duplexer/ CAN2 CAN Bus termination
