Motorola DIMETRA X Core User Manual

6802800U74-AN
Chapter 14: Technical Specifications
412
PSU Specifications Description
Weight 5 kg
14.3.18
XHUB Controller Specifications
The following table lists the XHUB controller performance specifications.
Table 138: XHUB Controller Specifications
XHUB Controller Specification Value or Range
Power Consumption 5 W to 8 W
Dimension Height: 240 mm
Width: 61 mm
Depth: 393 mm
Weight 2.2 kg
14.3.19
RX Splitter Specifications
The following table lists the RX Splitter specifications.
Table 139: MTS 4 Expansion Cabinet RX Splitter Specifications
RX Splitter Specification Value or Range
Dimension Height: 139 mm
Width: 124 mm
Depth: 45 mm
Weight 0.4 kg
14.3.20
MTS LiTE, MTS 2, and MTS 4 Connectors
Table 140: MTS LiTE/MTS 2 Connectors
Connector
Type
Description
External GPS
SUB D
DB15 Female connector
Alarms
SUB D
DB25 Female connector
E1
RJ45
Functionality described in Hardware installation
chapter
X.21
SUB D
DB15 Male connector
Functionality described in Hardware installation
chapter
