Motorola DIMETRA X Core User Manual

149
6802800U74-AN
Interconnection and Internal Cabling
Chapter 5
Interconnection and Internal Cabling
MTS installation requires proper interconnection and internal cabling. The connection types include:
• Power cabling
• User alarms and control cabling
• E1, Ethernet, and site link cabling
• RF cabling
• CAN Bus cabling
5.1
AC/DC Power Cabling
AC power cabling refers to the connection between the Junction Panel and the Power Supply Unit.
DC power cabling refers to the power connections between the Junction Panel and the Power Supply
Unit and between the Power Supply Unit and other modules within the cabinet.
5.1.1
AC/DC Power Cabling – MTS LiTE
Table 33: AC/DC Power Cabling for MTS LiTE
In-
dex
Cable Part
Number
From Unit/ Connec-
tion Name
To Unit/ Connection
Name
Notes
1 3066550B01 Junction Panel/ DC
Power Supply Unit/
DCIn Battery
N/A
2
3066556B01
Junction Panel/ Bat-
Temp.
3
3066552B02
Junction Panel/ AC
In
Power Supply Unit/
BatteryTemp.Sens.
Power Supply Unit/
ACIn
N/A
With retaining clip
4a
3066545B02
Power Supply Unit/
Base Radio 1/ DCIn
Pins: 1, 2, 3, 8, 10,
and 11
DC Out
4b
Site Controller/ Power
1
Pins: 7 and 14
