Motorola DIMETRA X Core User Manual

14
4
6802800U74-AN
Chapter 4: Hardware Installation
Item
Torque Nm
Torque lbfin
Screws M6 (Torx 30)
6 (minimum)
40
Nuts from M4 to M 6
4.5
40
M8 screw
15
130
M 10 Screw
6.8
60
DIN 7–16
25 – 30
221 – 266
4.13.5
Mounting Screws
The following table lists the screws used for mounting modules in MTS 2 and MTS 4 cabinets.
CAUTION:
Avoid cold welding.
When screwing in a stainless steel screw, do not apply any pressure to the power tool.
Table 32: MTS LiTE, MTS 2, and MTS 4 and Expansion Cabinets Mounting Screws
Module Part
Screws/Washers
Part Num-
ber
Tool
Site Controller and XHUB
2 pcs M4X10/captivatedstarwasher
0310909C6
1
Torx
20
Power Supply Unit
2 pcs M4X10/captivatedstarwasher
0310909C6
0
Torx
20
Base Radio
2 pcs M4X10/captivatedstarwasher
0310909C6
0
Torx
20
Filters in MTS 2
3 pcs M4X10/captivatedstarwasher
0310909C6
0
Torx
20
Filters in MTS 4
Mounting on the filter bracket:
2pcsM4X10/captivatedstarwasher
0310909C6
0
Torx
20
1 pc. M4X8 countersunk
0310913A35
Torx
20
Mounting filter bracket in the cabinet:
2 pcs M4X10/captivatedstar washer
0310909C6
0
Torx
20
Cavity Combiners
3 pcs M6X16, captivated star wash-
er
0310909C9
2
Torx
30
Hybrid Combiner
2 pcs M4X10, captivated star wash-
er
0310913A35
Torx
20
Fan Kit
1 pc M3X8, captivated star washer
0310909C3
2
Torx
10
RFDS front cover – MTS4/
4 pcs M6X16, captivated star wash-
0310909C9
Torx
Expansion Cabinet
er
2
30
